1.Mechanical characteristics
Teminal strength :5N for 1 Min
Ratating forque :0.5N ~ 1N
Withstａnd vibration properly :10~55~10Hz/swing1.5mm,x,y,z direction 2 hours
2.Electrical characteristics
Rated Power :DC 60V 0.3A Max.
Poles :1 or 2
Sections:2 .3.4.5.6.7.8
Contact resistance between terminals :50MΩ Max
Insulation resistance :500MΩ Min at DC 500V
Dielectric strength :1 minute at AC 500V
3.Endurance characteristics
| Rotational Life: | 10,000±200cycles |
| Storage Temperature Range : | -30C ~ +85C |
| Operaating Temperature Range | -20C ~ +80C |
| Soldering Heat Characteristic:Dipping in solder: | 230C±5C or less,within 3S |
| Solder by hand: | 360C±5C or less,within 3S |
