High accuracy,contains strong ability of anti-bias, fast response. Apply to electronic scales and crane scales.
用途与特点:
量程、规格、外形及安装尺寸:
额定载荷 Rated Load
|
3
~10(t)
|
综合精度 Comprehensive Precision
|
0.02 (
线性+
滞后+
重复性)
|
灵敏度 Sensitivity
|
1.5 mV/V
|
蠕变 Creep
|
±0.02%F·S/30min
|
零点输出 Zero Output
|
±1 %F·S
|
零点温度影响 Temperature Effect On Zero
|
±0.02 %F
·S/10
℃
|
输出温度影响 Temperature Effect On Output
|
±0.02%F
·S/10
℃
|
工作温度 Operating Temperature Range
|
-20
℃
~+65
℃
|
输入阻抗 Input Resistance
|
380
±10
Ω
|
输出阻抗 Output Resistance
|
350
±3
Ω
|
绝缘电阻 Insulation Resistance
|
>5000 MΩ
|
安 全过载 Safe Load Limit
|
300% F·S
|
供桥电压 Bridge Voltage
|
建议 10VDC
|
材质 Material
|
合金钢或不锈钢
Alloy Steel or Stainless Steel
|
传感器接线方式
Load Cell Mode of Connection
|
输入+:
红 Input+:Red
输入-:
黑 Input-:Black
输出+:
绿 Output+:Green
输出-:
白 Output-:White
|
