本机械式（Analog）拉压力计是一支体型轻巧操作简单易于携带且精度高之多用途品管试验用拉压力詈，峰值（PEAK）和瞬间值（TRACK）的转换，只要转动设定钮即可，操作轻而易举，迅速准确。备有AK（kgf刻度板）、AN（N刻度板）、NK（Kgf和N双刻度板）三种类，范围从1Kgf（10N）至50Kgf(500N)可供选择。The AN/NK/AK series are analog force gauges with compact size and high accuracy . They are easy to operate and handy to carry out .Single click on a knob on the device will convert the movement of the indication needle from the peak force indication (the needle stands still indicating peak force )to the tracking indication (the needle moves in accordance with change of force ).As three types of scales are available and each type has measurement capacity variations, you can choose the most suitable graduation from the range of 10N(1kgf)to500N(50kgf)for your measurement purpose. AK: kilogram scale:AN Newton scale and NK: Newton ａnd kilogram scale. 一、 特点 Characteristics 1.高解析度 (1/200) HIGH RESOLUTION 2.高精度 (0.5%) HIGH ACCURACY 二、规格 Specification型号No. 测试范围Max Load 最小刻度Min Load 行程Strok NK-10 10N 1Kgf 0.05N 5gf 10mm NK-20 20N 2Kgf 0.1N 10gf 10mm NK-30 30N 3Kgf 0.2N 20gf 10mm NK-50 50N 5Kgf 0.25N 25gf 10mm NK-100 100N 10Kgf 0.5N 50gf 10mm NK-200 200N 20Kgf 1N 100gf 10mm NK-300 300N 30Kgf 2N 200gf 10mm NK-500 500N 50Kgf 2.5N 250gf 10mm |
