广泛应用： 生物制剂、制药、电池、CV、热管、水剂、香水等液体的精密定量灌装。Precise quantity filling of liquids such as biological agents, pharmaceuticals, batteries, CVs, heat pipes, liquid agents, perfumes, etc.
产品性能：
l 结构紧凑、体积小、高精度、耐腐蚀、耐高温。
l 拆卸安装方便只需2分钟，可在线清洗。
l 精密丝电机驱动、高性能、长寿命，高强度可重复运行。
l 数字化触摸屏调解计量容量。
l 无易损件，零维修及保养成本。
l 防化学反应与大多数流体都兼容。
l Compact structure, small size, high precision, corrosion resistance and high temperature resistance.
l Easy to disassemble and install in only 5 minutes and can be cleaned online.
l Precision wire motor drive, high performance, long service life, high strength and repeatable operation.
l Digital touch screen mediates measurement capacity.
l No quick-wear parts, zero maintenance and repair costs.
l Anti-chemical reaction prevention is compatible with most fluids.
技术参数 Technical Parameters
|
规格型号 Specification & Model |
JKR-ZNX1-M500µl |
JKR-ZNX1-M1500µl |
JKR-ZNX1-M3500µl |
JKR-ZNX1-M6500µl |
JKR-ZNX1-M10ml |
|
柱塞材质 Plunger material |
氧化铝Alumina /氧化锆 zirconia /氮化硅 silicon nitride / 蓝宝石sapphire (可选optional) |
||||
|
阀向切换 Valve direction switching |
陶瓷阀旋转切换Rotary switching of ceramic valve |
||||
|
驱动方式 Driving mode |
精密丝杆/步进电机Precision screw motor |
||||
|
冲程速度 Stroke speed |
1-60r / min (preparation and selection) |
||||
|
调节方式 Adjustment mode |
数字化触摸屏调节Digital screen touch screen smart adjustment |
||||
|
单冲程范围 Single stroke range |
3-500µL |
5-1500µL |
20-3500µL |
50-6500µL |
0.1-10ml |
|
冲程精度 Stroke accuracy |
±0.3‰ |
±0.4‰ |
±5‰ |
±5‰ |
±5‰ |
|
进液管道 Liquid inlet pipe |
Φ2.5×4mm |
Φ4×6mm |
Φ6×8mm |
Φ6×8mm |
Φ6×8mm |
|
出液管道 Outlet pipe |
Φ1.0×1.6mm |
Φ2.5×4mm |
Φ4×6mm |
Φ4×6mm |
Φ4×6mm |
|
管道材质 Pipe material |
PE/PTFE (optional) |
||||
|
通讯接口 Communication interface |
RS23 2(485 optional), I/O, CC TRIG, AUX OUT |
||||
|
配制电源 Power supply |
220V/50HZA or 120V/60HZ (optional) |
||||
|
工作坏境 Work environment |
Use temperature and humidity 5-40℃, below 85%RH |
||||
