| ISO Centering Ring-ISO中心圈附O型环及外圈 ISO欧规中心圈-附外圈及O型环（Viton） |
|
|
|
|
|
|
|||||||||||
| Model No. | Parts No. | A | B | C | D | E | Material-C/R | Material-O/R | Material-O'Ring | O'Ring Size |
|
| ISO63OCRVSE | 192110421 | 68 | 70 | 8 | 3.9 | 94 | 304 S.S. | AI | Viton | AS-337 |
|
| ISO80OCRVSE | 192111421 | 81 | 82.6 | 8 | 3.9 | 109 | 304 S.S. | Al | Viton | AS-341 |
|
| ISO100OCRVSE | 192112421 | 100 | 102 | 8 | 3.9 | 128 | 304 S.S. | Al | Viton | AS-347 |
|
| ISO160OCRVSE | 192115421 | 148 | 153 | 8 | 3.9 | 179 | 304 S.S. | Al | Viton | AS-362 |
|
| ISO200OCRVSE | 192116421 | 210 | 213 | 8 | 3.9 | 238 | 304 S.S. | Al | Viton | AS-371 |
|
| ISO250OCRVSE | 192117421 | 257.5 | 261 | 8 | 3.9 | 287 | 304 S.S. | Al | Viton | AS-378 |
|
| ISO320OCRVSE | 192119421 | 312 | 318 | 12 | 5.6 | 344 | 304 S.S. | Al | Viton | AS-454 |
|
| ISO400OCRVSE | 192121421 | 394 | 400 | 12 | 5.6 | 446 | 304 S.S. | Al | Viton | AS-461 |
|
| ISO500OCRVSE | 192123421 | 494 | 501 | 12 | 5.6 | 535 | 304 S.S. | Al | Viton | AS-469 |
|
| ISO63OCRVAE | 192110121 | 68 | 70 | 8 | 3.9 | 94 | Al | Al | Viton | AS-337 |
|
| ISO80OCRVAE | 192111121 | 81 | 82.6 | 8 | 3.9 | 109 | Al | Al | Viton | AS-341 |
|
| ISO100OCRVAE | 192112121 | 100 | 102 | 8 | 3.9 | 128 | Al | Al | Viton | AS-347 |
|
| ISO160OCRVAE | 192115121 | 148 | 153 | 8 | 3.9 | 179 | Al | Al | Viton | AS-362 |
|
| ISO200OCRVAE | 192116121 | 210 | 213 | 8 | 3.9 | 238 | Al | Al | Viton | AS-371 |
|
| ISO250OCRVAE | 192117121 | 257.5 | 261 | 8 | 3.9 | 287 | Al | Al | Viton | AS-378 |
|
| ISO320OCRVAE | 192119121 | 312 | 318 | 12 | 5.6 | 344 | Al | Al | Viton | AS-454 |
|
| ISO400OCRVAE | 192121121 | 394 | 400 | 12 | 5.6 | 446 | Al | Al | Viton | AS-461 |
|
| ISO500OCRVAE | 192123121 | 494 | 501 | 12 | 5.6 | 535 | Al | Al | Viton | AS-469 |
|
